Prison 8Ga Black Powder Coated Fencing EN 10223 High Security

Black Powder Coated EN 10223-4:2012 Standard 10ft high Prison Mesh fencing

Prison Mesh fencing Description:

ANTI CLIMB FENCE is the ultimate heavy duty welded mesh panel providing the highest degree of security with excellent see through visibility. It has toe and finger proof profile. With spacing specification of 75mm x 12.5mm, it is impossible for fingers and toes to go through. Hence, it prevents anyone from climbing over the fence to reach the protected area.

ANTI CLIMB FENCE is also known as ANTI CUT FENCE. The fence is designed to make it very difficult to cut through the panel with simple hand tools. With wire thickness of 4mm and spacing of 75mm x 12.5mm, intruders can never cut off the fence.

With excellent see through visibility makes ANTI CLIMB FENCE ideal to use in areas where CCTV is in operation. It is also very suitable to use on commercial, residential, governmental and industrial properties where you can enjoy both the ultimate security without compromising the visibility of customers and others.

The high quality galvanising coating gives ANTI CLIMB FENCE users a worry free mind. This is because unlike many other mild steel fences, ANTI CLIMB FENCE is hot dipped galvanised and does not get rusted easily in a short period of time. As a result, low maintenance or maintenance free for a very long period gives the user a calm mind.

Prison Mesh fencing Introduction:

• Wire: 4 mm steel wire.

• Wire surface finish: galfan coating after welded, and then PVC powder coating (Min. 120 micron), or PVC powder painting.

• PVC coated color: black, dark green, brown, yellow, desert sand, bronze or other colors request.

• Mesh opening pattern: 70 mm × 8 mm, welded well at each intersection.

• Mesh sheet width: 2515 mm.

• Anti-climb mesh fencing panels and posts.

• Fence security toppings: Flat razor wire coils with barbed wire, concertina barbed wire, security fence spikes, or shark tooth spikes (coating according to the anti-climb fence panels).

  • Shark tooth spikes: width 35 mm, long teeth up to 58 mm.

  • Security anti-climb fence spikes:

    • Plate thickness: 2.0 mm

    • Base width: 65 mm.

    • Spike length: 35 mm short spikes, 70 mm long spikes.

    • Spikes pitch: 70 mm.

  • Razor wire

    • Style: flat razor wire or concertina razor wires.

    • Barb length: short barb or long barb.

    • Material: galvanised steel, stainless steel (for extremely corrosive environments).

    • Wire: high tensile 25 mm, aluminum/zinc wire, breaking load 7700 N.

    • Coil Diameter: 600 mm, 750 mm.

    • Number of loops: 55.

    • Extent length: 7.5 m.

  • Barbed wire

    • Galvanized and PVC coated barbed wire with 2 strands and 4 points.

    • Gauge of strand and barb wire: 11 gauge.

    • Barbs spacing: 3 inch.

Prison Mesh fencing Specification:

Wire Panels: 3" x 0.5" x 10.5ga (8' ht.) / 8ga (10' ht.) anti-climb mesh

Impasse II Rails: 2"sq x 11ga

I-Beam Posts: 3" x 2.75" x 12ga / 4" x 2.75" x 12ga

Heights: 8' & 10'

Prison Mesh fencing Feature:

• Anti-Cut and Anti-Climb Security

• Single Sided Installation

• Groundable Fence Solution Meeting IEEE Standards

• Integrated Design

• IBC Compliant Options Available

• PermaCoat Maintenance Free Finish

• Meets Buy American Act

• 10 Year Limited Warranty

Prison Mesh fencing Packaging:

358 mesh fence panels packed in wooden pallets and enveloped by plastic film then wrapped by tape firmly for the security of storage and transportation.

Prison Mesh fencing Application:

• Army Camp

• Gated Security

• Prison

• Industrial Factory

• Play Ground

• Stadium

• Housing Estate

• Detention Centre

• Carpark

• Public Hall

• Train Station

• Harbour

• Walkway

• Highway

• Sport Centre

• Airport

• School

• Lrt Station

• Dam Boundary

• Reserved Forest​​

​
